| SMA-2- System to predict the snowmelt | |
| Resolution | 0,1 % |
| Dimensions (mm) | aluminium frame: 3.000 x 600switch cabinet: 70 x 100 x 55 |
| Protection | IP 65 |
| Power supply | 10,5… 15 VDC |
| Power consumption | operating mode: max. 50 mA (for 5 sec.) / stand-by: < 2 mA |
| Operating temperature | -35°… 80° C |
| Output | SDI-12, RS-485, RS-485 MODBUS |
| Parameters measured |
|
| SSG-2 – System to measure snow water equivalent | |
| Measurement range | 0…200 mm SWE (only SSG)0…500 mm SWE (only SSG)01.000 mm SWE (SSG and SSG-2)02.000 mm SWE (SSG and SSG-2)03.000 mm SWE (SSG and SSG-2) |
| Resolution | 0.1 kg/m²≙0.1 mm SWE * |
| Accuracy | 0.3 % (FS) * |
| Measuring surface | 6.72 m² |
| Total weight SSG | 110 kg |
| Dimensions SSG (mm) | L = 2800W = 2400H = 70 |
| Protection | IP 68 |
| Power supply | 10… 30 VDC |
| Power consumption | max. 70 mA |
| Operating temperature | -40… 80°C |
| Max. inclination | 5° |
| Output | SSG 200 4 – 20 mA≙0… 200 mm SWESSG 500 4 – 20 mA≙0… 500 mm SWESSG and SSG-2 1.000 4 – 20 mA≙01.000 mm SWESSG and SSG-2 2.000 4 – 20 mA≙02.000 mm SWESSG and SSG-2 3.000 4 – 20 mA≙03.000 mm SWE |
| Others | Connecting box with lightning protection |
The Snow Melt Analyser (SMA) constitutes the ideal measuring solution for the analysis of snowmelt. With its help, melting processes in the snow can be detected and the water run-off can be ascertained and used for flood forecasts or for water management.
Features & Advantages
